About the product

This series of products is pilot acting solenoid valve with waterproof connector (external thread connectors) which offer protection from dust and water (IP6.5. or IP6.7 on specific request) based on the external thread structure. The spool valve of this solenoid valve is with high performance spool valve available both for 3/2, 5/2 or 5/3, and the CV value is availble to 1.1, 1.4 or 2.79.

Wiring diagram of the external thread connector

1, The left figure is a structural diagram of the waterproof connector which is with a threaded external tightening structure not only expands the cable range but also tightly clamps the cable to achieve the purpose of waterproofing and dustproofing. 2, After correctly installing with screw and gasket as the structure shown in the left figure, the coil's climate protection rating can reach IP66.

Main technology data

The model no., function and Dimension
